Unsurpassed Performance

• The Aruba 550 Series Campus Access Points with 802.11ax technology efficiently and simultaneously serves multiple clients, increasing data rates for both individual devices and as an overall system.
• Multi-user transmission with downlink and uplink Orthogonal Frequency Division Multiple Access (OFDMA) increases user data rates and reduces latency, especially for large numbers of devices with short frames or low data-rate requirements, such as voice and IoT devices.
• Multi-user capability with downlink multi-user MIMO improves network capacity by allowing multiple devices to transmit simultaneously.
• The Aruba ClientMatch technology will automatically attempt to group 802.11ax capable devices onto available AP radios with equivalent capabilities, so that the performance benefits of OFDMA are maximized. This means increased network performance and a boost in network capacity.
• In the optional tri-radio operating mode, the 5GHz radio is split up into two independent 4×4 MIMO radios with up to four spatial streams each. This enables even higher numbers of simultaneously connected client devices.

Smart Power Management

• The Aruba 550 Series Campus Access Points includes Aruba Intelligent Power Monitoring (IPM) which allows for a gradual upgrade of switching by allowing the APs to operate if there is not enough Power over Ethernet ( PoE) power.
• This feature enables the AP to continuously monitor and report its actual power consumption and optionally make autonomous decisions to disable certain capabilities based on the amount of power available to the unit.
• Aruba’s Smart PoE allows the existing infrastructure to power up APs. Smart PoE enables to configure two PoE ports to either aggregate their power (more power available) or use one as a redundant PoE power.
• As higher-performance 802.11ax access points drive more power consumption, Aruba NetInsight Green AP feature allows the 550 series access points to draw less power when it’s not being used, such as evenings when the buildings are empty.
