HPE ProLiant DL20 Gen10 Specifications

Drive Support

• Drive options:
  • 2 Non-hot plug LFF
  • 2 Hot plug LFF
  • 4+2 Hot plug SFF

Processor Specifications

• Processor Type: Intel®
• Processor Family: Intel® Xeon® E-2300 series
• Processor Core Availability: 4 to 8 cores, depending on the specific processor
• Processor Cache: Up to 16 MB Intel® Smart Cache, depending on the processor
• Number of Processors: 1
• Maximum Processor Speed: 5.0 GHz, depending on the processor

Memory Specifications

• Memory Type: HPE DDR4 Standard Memory
• Memory Slots: 4 DIMM slots (maximum)
• Maximum Memory Capacity: 128 GB
• Memory Protection Features: ECC (Error-Correcting Code)

Storage and Expansion

• Storage Controller: Intel® VROC SATA (formerly Intel® RSTe)
• Expansion Slots: 2 maximum (refer to QuickSpecs for details)

Network and Management

• Network Controller: HPE embedded 1Gb 2-port BCM5720 Network Adapter
• Infrastructure Management: HPE iLO5 (Integrated Lights-Out)

Physical Characteristics

• Form Factor: 1U

Warranty and Support

• Warranty: 3-years parts, 3-years labor, and 3-years on-site support with next business day response.
• Additional Coverage: Optional service upgrades available through HPE. For more information, visit HPE Services and Support.
