Technical Specifications

• Drive Support:

  • 8/12 LFF SAS/SATA/SSD
  • Up to 24 SFF SAS/SATA/SSD options
  • Standard 2 M.2 SATA SSD on primary riser
  • Optional rear drive configurations: 6 SFF, 3 LFF, 2 SFF, or 2 Dual UFF
  • Optional 20 SFF NVMe support (limited by Express Bay)

• Processor:

  • Intel® Xeon® Scalable series (8100/8200, 6100/6200, 5100/5200, 4100/4200, 3100/3200)
  • Cores: 4 to 28
  • Cache: 8.25 MB to 38.50 MB L3
  • Max Speed: 3.9 GHz
  • Supports 1 or 2 processors

• Memory:

  • Type: HPE DDR4 Smart Memory (Intel® Optane™ support on select processors)
  • Standard: 3.0 TB (24 x 128GB LRDIMM), 6.0 TB (12 x 512GB Persistent Memory)
  • Slots: 24 DIMM
  • Max Capacity: 6.0 TB with Persistent Memory

• Storage Controller:

  • Options: HPE Smart Array S100i, P408i-a, P816i-a, or E208i-a

• Network:

  • HPE 1 Gb 331i Ethernet adapter (4-ports)
  • Optional HPE FlexibleLOM

• Expansion Slots:

  8 (refer to QuickSpecs for details)

• Management:

  • HPE iLO Standard with Intelligent Provisioning
  • Optional: HPE iLO Advanced, HPE OneView Advanced

For more details, visit HPE Support.
